Mainboard GIGABYTE B660M GAMING X | Chính hãng

SKU: B660M GAMING X

Thương hiệu: Gigabyte

Còn hàng

4,150,000₫

Chính hãng 100%

Bảo hành

Hỏa tốc 1h (TP.HCM)

Giao toàn quốc

Bạn đang phân vân về sản phẩm Mainboard Gigabyte

Mainboard GIGABYTE B660M GAMING X | Chính hãng

1. Thông số sản phẩm

₋ Tên Hãng: GIGABYTE

₋ Tên sản phẩm: Mainboard GIGABYTE B660M GAMING X

₋ CPU hỗ trợ: Intel

₋ Chipset: B660

₋ RAM hỗ trợ

o Support for DDR4 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /3200/3000/2933/2666/2400/2133 MHz memory modules
o 4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
o Dual channel memory architecture
o Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
o Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
o Support for Extreme Memory Profile (XMP) memory modules

₋ Khe cắm mở rộng:

₋ Ổ cứng hỗ trợ:

CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)

₋ Chipset:

1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
4 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10

₋ Cổng kết nối (Internal)

o 1 x 24-pin ATX main power connector
o 1 x 8-pin ATX 12V power connector
o 1 x CPU fan header
o 3 x system fan headers
o 2 x addressable LED strip headers
o 2 x RGB LED strip headers
o 2 x M.2 Socket 3 connectors
o 4 x SATA 6Gb/s connectors
o 1 x front panel header
o 1 x front panel audio header
o 1 x USB Type-C® header, with USB 3.2 Gen 2 support
o 1 x USB 3.2 Gen 1 header
o 2 x USB 2.0/1.1 headers
o 1 x S/PDIF Out header
o 2 x Thunderbolt™ add-in card connectors
o 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
o 1 x serial port header
o 1 x reset button
o 1 x Q-Flash Plus button
o 1 x reset jumper
o 1 x Clear CMOS jumper
